Thermogravimetric Analysis (TGA)

Thermogravimetric, or thermal, analysis (TGA or TG) measures changes in sample weight in a controlled thermal environment as a function of temperature or time. The changes in sample weight (mass) can be a result of alterations in chemical or physical properties and can be detected to a fraction of a microgram. TGA is useful for investigating thermal stability of solid or liquid materials under conditions of ramping temperature in an inert gas atmosphere or in an oxidative gas atmosphere. TGA can also be conducted at constant temperature to evaluate thermal stability of materials over a specific time period. For example, potential VOC emission from pesticides can be measured at constant temperature for determining the amount and rate of mass loss over a specified time period.

Coupling the TGA to a spectrophotometer allows the study of volatile species and pyrolysis products, which can lead to discovering how a compound or formulation degrades and what components it contains. For example, TGA coupled with mass spectroscopy (MS) can provide specific information on chemical structure for identifying additives, contaminants and composition of blends and copolymers (TGA-EGA).

Ideal Uses of Thermal Analysis

  • Thermal stability/degradation
  • Quantitation of volatiles/moisture
  • Screening of additives
  • Evolved gas analysis (TGA with MS or TGA with FTIR (TGA-EGA)
  • Vaporization or sublimation
  • Deformulation of organic/inorganic mixtures (e.g. ink, paste, polymer composites)
  • Loss on drying
  • Residue/filler content
  • Decomposition kinetics
  • Characterization of medical device polymer materials, such as polyurethane foams

Strengths

  • Small sample size
  • Analysis of solids and liquids with minimal sample preparation
  • Qualitative or quantitative analysis
  • Detection of multiple mass loss thermal events from physical and chemical changes of materials
  • Separation of overlapping mass loss thermal events (High Resolution TGA)

Limitations

  • Evolved products are identified only when the TGA is connected to a spectrophotometer (e.g. TGA/MS or TGA/FTIR). This technique is available at EAG Laboratories in some supporting locations

Thermal Analysis Technical Specifications

  • Signal Detected: Mass change and temperature
  • Maximum Sample Weight: 1 gram
  • Temperature Range: Ambient to 1000°C (1100°C available at some supporting locations TG-DTA)
  • Controlled Heating Rate: 0.01 to 100°C/minute
  • Weighing Precision: +/-0.01%

The following are available options that are offered at some supporting locations:

  • High Resolution TGA
  • Evolved Gas Analysis TG-EGA
  • TGA/MS Analysis
  • TGA/FTIR Analysis
  • 1100°C Upper Temperature Limit
  • Simultaneous Thermal Analysis (STA): Combined TGA and Differential Thermal Analysis measurements in a single instrument: TG-DTA
