EAG Laboratories proudly announces the launch of our upgraded EBSD service with revolutionary high-speed, high-sensitivity CMOS detector. With this powerful tool we can give direct visualization of crystal microstructure over a wide scale range: down to several 10s of nanometers and up to several 10s of millimeters. Not only is local characterization available (accurate pin-down of scanning locations), statistical information can also be generated. Some typical information extracted from EBSD data includes grain size/shape, grain boundary misorientation, texture, slip planes, and phase identification.
The CMOS technology base detector has the highest sensitivity and dynamic range on the market, which enables its ability to work with lower current input. Many beam sensitive samples and insulators can now benefit from the use of this new detector.
Automatic large-area scanning-and-stitching function is available with the new tool. We can now offer continuous scan over large areas of intreat without sacrificing the local details.
Integrated EDS and EBSD scans offer the ability to differentiate phases with same crystal structure but different chemistry. Spatial distribution of chemical elements with correlating EBSD result gives a complete view of the microstructure.
We now offer Transmission EBSD (TKD) analysis for refined microstructure. The technique calls for standard TEM preparation and gives EBSD data at exceptional spatial resolution. Forward scatter detectors are integrated on the front of the detector giving high contrast images with information of element number Z and topographical features.
Eurofins EAG Laboratories tackled the problem of quantification of both major and minor elements in nonuniform, multi-element matrices with continuously graded composition changes using Point-by-point CORrected-SIMS.
The elemental purity of boron carbide can be measured using several methods offered by Eurofins EAG Laboratories
Eurofins EAG Laboratories stands ready to assist in the analysis of lithium-ion batteries from the raw material supply chain through to the finished product and eventual recycling.
EAG’s material and microelectronic testing service is dedicated to providing the best information from ensuring the purity of starting materials, to prototype testing of devices in the ramp up towards full-scale production.
